DY5 – dual charger for Yuneec H520 and Typhoon H Plus

The new DY5 dual charger allows you to charge two Yuneec H520 or Typhoon H Plus batteries at once. We haven’t had the chance to try it out yet but apparently, it is really simple; insert the batteries into the compartments and the DY5 dual charger will automatically.

About the DY5 – dual charger

The DY5 dual charger has two different color displays that display the charge time, cell voltage and real-time battery capacity. You can also charge the ST16S remote controller via the integrated USB output. The charger also offers a special storage feature that will prepare the battery for optimal long-term storage conditions.

Key Features

• Dual Charger – fast charge circuit for rapid charging of H520 or Typhoon H Plus batteries
• Dual TFT color screen for displaying charge time, cell voltage, real-time battery capacity and capacity percentage
• Function to create an optimal storage capacity
• AC current input 100-240V for global compatibility
• Protection against short circuit, overcurrent and over temperature failure
• USB output

Technical Specifications

• Dimensions: 178 x 177 x 65 mm
• Weight: 790 g
• Input Voltage: 100-240V AC
• Output Voltage: 17.4 Volt
• Charge Current: 6.0A x 2
• Battery Cell Count: 4 cell
• Balancer: 400 mA/cell
• Charge Output: Dual Independent Output
• USB Output: 5V / 2.0A
